PU shutter door Machine Technical Data

1. Steel Sheet Thickness: 0.27-0.4mm (depend on requirement )

2. Cutting: fly saw cutting

3. Transmission way: chain

4. Material of blad: Cr12, quenching treatment

5. Capacity of Decoiler: 3 ton hydraulic decoiler

6. Forming Speed: 8-15m/min

7. Roller Groups: 46 stations

8. Roller Material: GCr15 grade steel, quenching treatment

9. Material: color-coated galvanized steel

10. Principal Axis: 45# high grade steel with quenching treatment

11. Main Motor Power: 11 Kw

12. power supply: 380V, 50Hz, 3Phase


Production Line Machine List

Standard Profile :













Working Flow of Octagon Pipe Roll Forming Machine


Uncoiling – feed Guiding–Roll forming ––fly saw cutting – Run-out table



Photo Gallery





















Loading pictures

The main products of factory is light gauge framing machine, pre-painted steel forming machine, Glazed Tile forming machine, Automatical C/Z Purlin forming machine, Floor Deck forming machine, Guardrail forming machine, Down Pipe forming machine, The whole carriage plate for car beam unit , Steel storage unit, etc. Totally it has 100 types in 20 serious. The products are widely used in warehouse, factory buildings, supermarket, Nursing homes, villas, residential, greenhouse and other construction projects. Our factory can meet the construction enterprises, automobile industry, iron and steel production enterprises’s growing demand.
