Main Motor Power 22kw Guard Rails Roll Forming Machine Material Thickness 3-5mm

• main motor power: 22kw
• station: adopt cast iron HT50
• Decelerating motor: BWD14-43-37KW, made in Shanghai or Changzhou
• drive: gear box driving
• main shaft dia: ￠120mm material: 45﹟forge steel
• roller material: GCR15 quenched 58°-62°,chromed
• roll station:15stations
• roller thickness: 3-5mm
• Timing by transducer:5m--20m/min(not including punching)
• Transducer: Panasonic made in Japan. 380V 50HZ
• Computer: PLC
• Computer operating panel: touching screen

Flow Chart

Decoiling—Feeding (take the sheet to the first station)—leveling----Punching of the sheet ---- hydraulic cut to length—— roll forming----outtable

Machine Components

Profile Drawing

The main products of factory is light gauge framing machine, pre-painted steel forming machine, Glazed Tile forming machine, Automatical C/Z Purlin forming machine, Floor Deck forming machine, Guardrail forming machine, Down Pipe forming machine, The whole carriage plate for car beam unit , Steel storage unit, etc. Totally it has 100 types in 20 serious. The products are widely used in warehouse, factory buildings, supermarket, Nursing homes, villas, residential, greenhouse and other construction projects. Our factory can meet the construction enterprises, automobile industry, iron and steel production enterprises’s growing demand.
